Smittybilt XRC 3.0 User Manual

WWW.SMITTYBILT.COM
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Installation Instructions
XRC 3.0 3,000lb Winch
Part # 97203
NO S.B part# QTY Description
1 97203-01 1 Motor
2 97203-02 1 gasket
3 97203-03 1 bearing
4 97203-04 1 bearing bushing
5 97203-05 1 brake base
6 97203-06 1 brake gear
7 97203-07 1 drum support motor side
8 97203-08 2 drum bushing
9 97203-09 2 tie rod
10 97203-10 1 bushing for water proof
11 97203-11 2 o-ring for water proof
12 97203-12 1 drum
13 97203-13 1 spring
14 97203-14 2 Split snap ring
15 97203-15 1 shaft
16 97203-16 1 gear box cover
17 97203-17 1 Gasket
18 97203-18 1 splined gear
19 97203-19 1 Gear carrier assembly state 3
20 97203-20 1 Gear carrier assembly state 2
21 97203-21 1 Gear carrier assembly state 1
22 97203-22 1 sun gear
23 97203-23 1 gasket
24 97203-24 1 Slide block for clutch
25 97203-25 1 gear ring
26 97203-26 1 gear box body
27 97203-27 1 bushing
28 97203-28 1 clutch knob
29 97203-29 1 wire rope and hook
97203-30 1 Remote
97203-31 1 Handle Bar Control
97203-32 1 Winch Plate
97203-33 1 Solenoid
