Smittybilt XRC 8 User Manual

For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Page 9 of 17
XRC 8 Specifications
XRC 8 SpecificationsXRC 8 Specifications
XRC 8 Specifications
Rated Line Pull: 8000Lbs (3600kgs) single-line
Motor: 5.5hp /12V, Series Wound
Control: Remote Switch, 12’ (3.7m) lead
Gear Train: 3-Stage Planetary
Gear Ratio: 172.8:1
Clutch: Rotating Ring Gear
Brake: Automatic In-The-Drum
Drum Size: (Diameter x Length) 2.5” x 8.82” (63.5mm x 224mm)
Wire Rope: (Diameter x Length) 21/64” x 94’ (8.2mm x 28.5m)
Fairlead: 4-Way Roller
Remote Control: Included
Recommended Battery: 650CCA Minimum for Winching
Battery Leads: 25mm
2
, 72” (1.8m)
Finish: Black
Weight: 94.0lbs (42.5Kgs)
Mounting Bolt Pattern: 10.0” x 4.50”
Line speed and amp draw (first layer)
Lbs 2000 4000 6000 8000
Line Pull
Kgs
NO LOAD
910 1814 2720 3630
Fpm 37.2 18 13.1 10.2 8.2
Line Speed
Mpm 11.4 5.5 4.1 3.2 2.6
Motor Current Amps 75 195 260 335 410
Line pull and cable capacity
Layer of cable 1 2 3 4
Lbs 8000 6900 5850 5100
Rated line pull per layer
Kgs 3630 3130 2650 2310
Ft 16 42 72 94
Cable capacity per layer
Mpm 5 12 21 28
