9. Align the pin of the top hinge with top hole on the left
side of the door and push into place. Replace the screws in the
upper hinge bracket but do not tighten all the way. (see fig. # 2)
10. Make sure the door closes easily but forms a tight seal.
Adjust the door as needed. Once you are satisfied with the door
alignment, completely tighten the upper door hinge screws.
11. Replace the hinge cover. (see fig. # 2)
12. If the door does not close properly, refer to the
section titled “Door Alignment”.
NOTE: As the door gets pressed-in during shipping, after reversing the
door the gasket may have to be reset. This is done to prevent
the cool refrigerated air from escaping. If there is a gap
between the door gasket and the cbainet, set the gasket by
gently pulling it out to seal the gap.
fig. # 3
door pin
lower hinge bracket
screw hole plug
