SNAIGE RF53SG - Page 8

7
The transparent cold section 0 °C Fresh ZONE drawer 5 moves on roller bearings 17. The
drawer can be removed by pulling it out, and lifting it off the rails
RF57SG, RF53SG
A – refrigerator compartment
B – freezer compartment
1
Control panel
9
Fast-freeze section
2
On / off switch for interior light
10
Frozen products section(s)
3
Height-adjustable shelves
12
Egg tray
4
Shelf for bottles
13
Door trays
5
Cold section drawer 0 °C Fresh ZONE
14
Condenser
6
Glass shelf
15
Thaw water drip tray
7
Fruit and vegetable drawer Fruit&VEGS
16
Compressor
8
Section for freezing small products
