8
Operating Instructions EEBC302A
A—Charging Mode Switch
Two-position rocker amperage charging rate mode switch
selects continuous charging of 35 amps in low position or 70
amps in high position and UL Cranking Assist output of 250
amps DC.
B—Length of Charge Timer
Selects charger power mode and charge duration with manual
or automatic shut-off functions.
• OFF electrically shuts off power to the charger.
— Select before connecting or disconnecting power cord or
any leads.
• HOLD powers charger until OFF is manually selected.
— Select when desired charge time exceeds 120 minutes.
Charger does not turn off automatically when this function
is selected.
• CHARGE TIME is number of minutes the charger operates
before automatically shut-off. Charger shuts off automatically
after number of minutes selected lapse when this function is
selected.
— Up to 120 minutes can be selected. Increase or
decrease charge time as needed by selecting new time.
✓✓
✓✓
The charger automatically shuts off when the charge
time reaches zero.
C—Ammeter
Displays amps, 0 to 100 DC, flowing from charger into battery.
AC Power Cord (Not shown)
Extends 9.5 feet from back of charger.
DC Leads (Not shown)
Extend 7 feet from back of charger.
