8
Section 2 - OPERATING INSTRUCTIONS
2.3 STARTING & OPERATION
2.3.1. ENGINE (ELECTRIC START) (Continued)
8. Should the battery be too weak to start the engine,
refer to Section “ENGINE (MANUAL START)” to
manually start the electric start engines.
9. On Model 3314522BVE, the engine is equipped
with a fuel shut-off solenoid. If the battery is dead, the
engine can be started with the recoil back-up starter if
the throttle control is in the choke position (HOT engine
or COLD engine).
2.3.2. ENGINE (MANUAL START)
IMPORTANT: When the ignition key is turned to
“ON”, and the recoil handle is pulled, the engine will
turn over, but will
not start unless the Clutch/Brake
Pedal is pressed all the way down with Parking
Brake engaged (See Figure 2.8) and the Blade
Lever is in the “Off” position (See Figure 2.4). Start
engine as follows:
1. Move transmission shift lever to (N) Neutral
position. DO NOT start engine with transmission shift
lever in a drive position.
WARNING
It is possible to start engine with transmission shift
lever in a drive position. Follow starting instructions
carefully.
2. Make certain the Blade Lever is in the “OFF”
position. See Figure 2.4.
3. Press Clutch/Brake Pedal all
the way down,
move Parking Brake Latch over and release the
Clutch/Brake Pedal to set Parking Brake. See
Figure 2.8.
FIGURE 2.8
4. Open vent on fuel filler cap by turning
counterclockwise. NOTE: Failure to open vent on
the fuel filler cap can cause engine to stall.
5. Move engine speed control to the choke position
to start a cold engine. See Figure 2.6.
6. Turn key to “ON” position. See Figure 2.9.
FIGURE 2.9
7. Pull starter rope with a smooth, even motion until
engine starts. Always guide the starter rope back
into the recoil housing. Never allow rope to snap
back. After Engine starts, move engine speed
control to the “FAST” position.
8. Allow a brief warm-up until engine runs smooth.
TO START ENGINE,
PUSH CLUTCH/BRAKE
PEDAL ALL THE DOWN
MOVE
PARKING
BRAKE
LATCH
KEY
