7
Section 2 - OPERATING INSTRUCTIONS
2.1 PRE-START CHECK LIST
Make the following checks and perform the service
required before each start-up.
2.1.1. Check tires and add or release air as needed
to bring pressure to 12 PSI in front and 12 PSI in rear
tires.
2.1.2. Check guards, deflectors and covers to make
sure all are in place and securely tightened.
2.1.3. Check engine oil and add oil as needed to
bring level up to the FULL mark. Refer to engine
owner’s manual for oil specifications. See Figure 2.1.
FIGURE 2.1
2.1.4. Adjust seat as needed to most comfortable
position. Refer to Section “OPERATOR’S SEAT
ADJUSTMENT”.
2.1.5. Check blade control to insure it works freely.
If blade pedals are depressed, blade lever can be
moved manually from “ON” to “OFF” to stop
blade.
2.1.6. Check Reverse Lockout Mechanism. With
blade pedals depressed, shift lever must not go into
reverse.
2.1.7. Clean exterior surfaces of cutting deck and
engine of any accumulation of dirt, grass, oil, etc.
Keep engine air intake screen and cooling fins clear
at all times.
2.1.8. Add fuel to tank after pushing the Rear Engine
Rider outside where fumes can dissipate. Make sure
fuel filler cap is tight and vent is open after refueling.
Refer to engine owner’s manual for fuel
specifications. See Figure 2.2.
FIGURE 2.2
2.2 OPERATOR’S SEAT ADJUSTMENT
2.2.1. FRONT TO REAR ADJUSTMENT
1. With the engine stopped, loosen the two adjusting
knobs and move seat to desired position. After
adjustment, tighten knobs securely. If seat does not
move after loosening knobs, it may be necessary to
loosen the 5/16” patch lock screws or hex nuts
located at the rear of the seat. See Figure 2.3.
FIGURE 2.3
SAFE LEVEL
AREA
OPEN
VENT
FUEL
FILLER
CAP
FUEL
TANK
ADJUSTING
KNOBS
OPERATOR’S
SEAT
5/16” PATCH LOCK
SCREWS (DO NOT
OVERTIGHTEN
ADJUSTING
KNOBS
OPERATOR’S
SEAT
HEX NUTS
(DO NOT
OVERTIGHTEN)
