Snapper 3500 PSI Pressure Washer
17
PARTS LIST — UNIT
Item Part # Qty. Description
1 L189641GS 1 BASE
2 B2043GS 8 BOLT, Carriage
3 187978GS 1 KIT, Handle Hardware
4 C190293GS 1 HANDLE
5 CB1981GS 2 SUPPORT, Handle
6 99583GS 8 NUT, Hex Flange
7 B2150GS 1 HOOK, 5/16" Square Neck Gun
8 B2516GS 3 CAP, Black Vinyl
9 CB1982GS 1 BUMPER
10 30809GS 6 GROMMET
11 187974GS 1 DECAL, 5 QD Nozzles
12 190615GS 1 DECAL, Unit
13 190100GS 2 ASSEMBLY, Wheel
14 190146GS 2 PUSHNUT
15 48031GGS 1 CLAMP, Hose
16 A1040DGS 1 HOSE, Chemical Inject
17 A1041GS 1 FILTER, Chemical Hose
18 B4805GS 1 HOSE
19 87815GS 1 GOGGLES, Safety
20 B1436BGS 1 GUN, with Molded Grip
21 23645GS 4 CAPSCREW, Socket Head
22 22237GS 4 LOCKWASHER
23 190667GS 1 MANUAL, Owners
24 B3858GS 1 ASSY., Wand Ext. with QD
25 MS6321 1 MANUAL, B&S, Vanguard
26 BB3061BGS 2 OIL BOTTLE
Item Part # Qty. Description
27 188287GS 1 KIT, Nozzle Cleaning
28 B5830GS 1 KIT, O-Ring Maintenance
29 188194GS 1 BLIND RIVET
30 71693GS 1 FLAT WASHER
31 27007GS 1 VIB MOUNT, Donut Type
33 185805GS 1 PUMP, Assembly
(see pages 18-21)
34 21217GS 4 MOUNT, Vibration
35 67989GS 4 NUT, M8, Flange
36 B4224GS 1 SCREEN, Gun Inlet
37 95320GS 1 INLET, Garden Hose
38 97837GS 1 O-RING, High Pressure Hose
39 95458GS 1 QUICK CONNECT
40 B1554GS 1 VALVE, Thermal Relief
41 B4847GS 1 KIT, Nozzles QD
42 63281GS 1 KEY
43 187952GS 1 DECAL, Cool Down System
44 190277FGS 1 CARD, Owners Registration
45 190616GS 1 DECAL, PW, Snapper
46 11287628PGS 1 DIPSTICK, Pump
47 B2384GS 1 FILTER, Inlet
48 B4160GS 1 DECAL, Warning/Start
49 B3107GS 1 HOSE, Thermal Relief
50 48031BGS 2 CLAMP, Hose Band
51 B1880GS 4 NUT, M8, w/Washer
900 NSP 1 ENGINE
