Snapper 3500PSI User Manual

Snapper 3500 PSI Pressure Washer
19
PARTS LIST — PUMP
Item Part # Qty Description
0 187263GS 0 Complete Pump Assy (see also pages 20-21)
1 101B2327GS 6 Plug
2 100B2327GS 6 O-Ring
3 102B2327GS 6 Valve
4 103B2327GS 6 O-Ring
5 104B2327GS 2 Plug
6 105B2327GS 2 O-Ring
7 106B2327GS 3 Support Ring
8 107B2327GS 3 Gasket
9 108B2327GS 3 Piston Guide
10 109B2327GS 3 O-Ring
11 110B2327GS 3 Gasket
12 186381GS 3 Seal
13 112B2327GS 4 Screw
14 113B2327GS 1 Bearing Support
15 132B2327GS 3 Shim
16 114B2327GS 1 O-Ring
17 186382GS 1 Bearing
18 186383GS 1 Pump Housing
19 117B2327GS 1 Oil Cap
20 118B2327GS 3 Nut
21 119B2327GS 3 Washer
22 120B2327GS 3 Piston
23 121B2327GS 3 Spacer
24 122B2327GS 3 O-Ring
25 161B2327GS 3 Ring
26 123B2327GS 3 Piston Guide
27 124B2327GS 3 Piston Pin
28 186384GS 3 Con Rod
29 118B2126GS 1 Cover
30 1343501GS 4 Screw
31 186385GS 2 Plug
32 134B2327GS 3 O-Ring
33 116B2126GS 1 O-Ring
34 142B2126GS 4 Screw
35 150B2126GS 1 Flange
36 139B1410GS 1 O-Ring
37 138B1410GS 1 Seal
38 137B1410GS 1 Bearing
39 152B2126GS 1 Grub Screw
40 186386GS 1 Shaft
41 136B2327GS 1 Plug
44 139B2327GS 1 Pump Head
45 159B2327GS 8 Washer
46 140B2327GS 8 Screw
47 B1554GS 1 Thermal Relief Valve
