Snapper 3500 PSI Pressure Washer
21
PARTS LIST — UNLOADER
Item Part # Qty Description
0 153B2126GS 0 Complete Unloader
1 210B2327GS 1 Hose Tail
2 231B2327GS 3 O-Ring
3 211B2327GS 1 Stainless Ball
4 212B2327GS 1 Spring
5 213B2126GS 1 Injector Body
7 215B2327GS 1 Injector Nut
8 137B2327GS 1 O-Ring
9 216B2327GS 1 Spring
10 217B2327GS 1 Plunger
11 218B2327GS 1 O-Ring
12 220B2327GS 1 Spacer Plate
13 221B2327GS 1 Spring
14 222B2327GS 1 Spring, Spacer Plate
15 219B2327GS 1 Upper Piston
16 223B2327GS 1 Pin
17 224B2327GS 1 Ring
18 225B2327GS 1 O-Ring
19 226B2327GS 1 Inlet Bolt
20 227B2327GS 1 Washer
21 228B2327GS 1 Valve Housing
22 229B2327GS 2 Ring
23 230B2327GS 1 Washer
24 232B2327GS 1 Lower Piston
25 234B2327GS 1 O-Ring
26 233B2327GS 1 Piston Guide
27 235B2327GS 1 O-Ring
28 241B2327GS 1 Suction Fitting
29 240B2327GS 1 O-Ring
30 239B2327GS 1 Washer
31 238B2327GS 1 Bypass Fitting
32 237B2327GS 1 Washer
33 236B2327GS 1 Inlet Bolt
34 248B2327GS 1 Plug
35 155B2327GS 1 Screw
36 246B2327GS 1 Nut
37 245B2327GS 1 Knob
38 243B2327GS 1 Housing
39 244B2327GS 1 Pin
40 242B2327GS 1 Spring Guide
41 95320GS 1 Garden Hose Connector
42 95458GS 1 Quick Connect Connector
