Snapper Model 030215 Portable Generator
3
EXPLODED VIEW - PARTS LIST
Item Part # Description
1 M189503GS CRADLE
2 194150GS KIT,Vibration Mount 45°
4 190220GS HOUSING, Engine Adapter
5 NSP ASSY,Alternator (see page 4)
6 194151GS KIT, Hardware Mounting Adapter
8 96796GS WASHER, M8 Flat
10 190274BGS SBHCS, 3/8-16 x 1.0 Lg.
11 187365FGS HHCS, 5/16-24 x 7-7/16
14 194729GS KIT, Muffler Bracket w/ Hardware
15 695398 GASKET, Exhaust
17 189008GS MUFFLER
18 60706GS SCREW, 5/16 - 18 x 3/4"
19 83083GS SCREEN, Spark Arrest
20 B4986GS DECAL, Ground, Green
21 194153GS KIT,Vibration Mount
22 86494GS SCREW,Wing M6 1.0 x 16
23 86292GS SCREW, 10-16 x 3/4 Self Drill
24 194390GS SHIELD, Heat
25 191190GS CAP
26 74908GS SCREW, M5-0.8 x 10,Taptite
31 191436GS DECAL, Hot Muffler
34 195422GS COVER, Bearing Carrier
35 194265GS KIT, Fuel Hose w/ Clamps
37 B2153GS SCREW, 12-14 x 7/8 Self Drilling
38 56893GS SCREW, 10-24 x 1/2 Crimptite
40 195477GS KIT, Fuel Tank Hardware
41 192980GS KIT,Valve,Tank
44 194217GS ASSY,Tank, Fuel (Includes Items 41, 50, 51 & 52)
45 90878GS CAP, Fuel Gauge
48 195373GS WIRE, Ground
50 188333GS DECAL, Gas Fill
51 194799GS DECAL, Danger
52 189235GS DECAL, Start Instructions
54 194448GS KIT, Insulation w/ Clip
55 191435GS DECAL, Fuel Shut-off
58 190355GS ASSY, Control Panel (see page 5)
59 * NUT, Palnut, 3/16"
60 194389GS SHIELD, Heat
900 § ENGINE
Parts Not Illustrated
BB3061GS BOTTLE, Oil
195609GS MANUAL, Owners
MS5242 MANUAL, Engine
195706GS KIT, Decals, SRV
* - Items without part numbers are common fasteners and are available at your local hardware store.
§ - Contact Engine Manufacturer
