Not for

Reproduction

Footnotes:

Manual No.

710616722" STEEL DECK WALK BEHIND

SERIES 20

Drive System, Self Propelle

Part No Descri

tionItem Qty

44 7046784YP 1 BELT, Engine Drive (Stretch)

45 7073528YP 1 DRIVE DISC, Steel

46 703971 1 BUSHING, 0.385 ID X 0.925 OD X 1.018 Thk, ZC/CL (Was 7017696 or 80005376)

47 690272MA 6 NUT, 5/16-18, Serated Lock Flange, GR5, Zinc/Clear (Was 7091601 or 80002728)

48 7029025YP 1 SPRING, Extension, .58 x 3.2

49 703798 2 BOLT, 5/16-18 X .50, Carriage, Zinc/Clear (Was 7090731, 725993, 908156MA or 80004563)

50 703447 1 BOLT, 5/16-18 X .625, Carriage, GR5, Zinc/Clear (Was 1931332, 703125, 7090799, 7091026 or

80003584)

51 703297 2 RETAINER, 5/16 X .625, Push Nut, GR 5, Zinc/Clear (Was 028X64MA, 5025498, 7011791,

720372 or 80002734)

52 703457 1 NUT, 3/8-16, Hex, GR 5, Zinc/Clear (Was 7091302 or 80004413)

53 7052987BMYP 1 ASSEMBLY, Deck Bracket, P21S

54 7033774YP 1 BRACKET, Deck, P21S

55 703941 1 SPACER, .50 ID X .650 OD X 1.750, Thk, ZC/CL (Was 7021758 or 80005392)

56 703973 2 BUSHING, Flanged, .381 x .625 x .62, Metal, CZ/CL (Was 7012306 or 80005378)

57 7600173YP 1 ASSEMBLY, Idler Arm, Bushing & Spacer (Was 7500154BMYP)

58 7032832AYP 1 ARM, Clutch Idler

59 703974 1 SPACER, Idler Arm (.500 ID x .970 Long), ZC/CL (Was 7100447 or 80005379)

61 7051913YP 1 ASSEMBLY, Clutch Idler

62 7061275YP 1 ASSEMBLY, Drive Disc, Square, P21S (Was 7053263YP)

63 7061276YP 1 KIT, Bushing & Hub Assembly (Was 7053217)

64 ---- 1 HUB, Driven Disc, USE 7061276YP

65 7011108YP 1 BUSHING, Hex Drive, 1.2”, .75” OD, .512” ID, Black Nylon

66 7600109YP 1 KIT, Driven Disc Assembly (Was 7501000)
