Snapper 7800849 Parts Manual

Not for
Reproduction
Footnotes:
Manual No.
710616722" STEEL DECK WALK BEHIND
SERIES 20
17
Transmission - Differential Group
Part No Descri
p
tionItem Qty
0010 7011110YP 4 SHAFT, Pinion
0040 7011774YP 1 GASKET, Housing
0050 7012495YP 1 GEAR, Differential, 46 Tooth
0060 703933 4 SPACER, .700 OD x .480 ID x .380 L, ZC/CL (Was 7012500 or 80005383)
0080 7019213YP 1 PULLEY, Poly-V Belt (3.5 O.D.)
0090 7021115YP 4 GEAR, Pinion (12 Tooth)
0100 7031965YP 2 WASHER, 1.25 X .765 X .03, Thrust, ZC/CL (Was 80003519)
0110 7031970YP 2 PLATE, Differential Gear, V21
0120 7050767YP 1 ASSEMBLY, Input Gear
0130 7051903AYP 1 WELDMENT, Differential Bracket
0140 7053943YP 1 ASSEMBLY, Transmission
0140-10 703934 1 SPACER, .820 OD X .720 ID X .330 L, ZC/CL (Was 7012543 or 80005384)
0140-20 7050830YP 1 ASSEMBLY, Short Axle (Was 7051932)
0140-30 7050831YP 1 ASSEMBLY, Long Axle (Was 7051933)
0150 7053939YP 1 ASSEMBLY, Left Housing (Was 7053938)
0150-10 7012314YP 2 SEAL, 5/8” ID
0150-20 7029033YP 1 HOUSING, Left Hand
0150-30 7029035YP 2 BEARING, Tapered, Differential Housing
0160 7051908YP 1 ASSEMBLY, Housing, Right Hand (Was 7053941)
0160-30 703935 3 BOLT, 5/16-24 x 1-1/8” Rib Neck, GR 5, ZC/BK (Was 7014155 or 80005385)
0160-40 7024442YP 3 GASKET, 5/8” O.D.
0160-50 7029034YP 1 HOUSING, Right Hand
0160-70 7073963YP 1 BEARING, Ball, 1.125 OD, .440 ID, 3.8 Wide
0170 703936 3 WASHER, .325 ID X .850 OD X .041 Thk, Internal External Lock, Type A, ZC/CL (Was 7090189
or 80005386)
0180 703937 4 NUT, #10-32 Nyloc, GR A, ZC/CL (Was 7090376 or 80005387)
0190 703938 4 SCREW, #10-32 x 1-1/2 Hex Head Cap GR5, ZC/CL (Was 7090557 or 80005388)
0210 703349 1 WASHER, .453 X .75 X .073, Flat, ZC/CL (Was 7091720 or 80004406)
0220 703459 4 NUT, 5/16-24, Hex Crown Lock,GR C, Zinc/Clear (Was 7092062 or 80004410)
0230 703939 1 WASHER, .32 ID x 1.40 OD x .10 Thk, Bellville, ZC/CL (Was 7092063 or 80005389)
0240 703833 4 SCREW, 1/4-20 x 1 Hex Washer Self-Tap, ZC/CL (Was 7091825, 7092064 or 80004415)
0250 703931 1 PLUG, Transmission Housing (Was 7016544 or 80005381)
0260 7061017 GREASE, “OO” (4 oz max) (Not Shown)

Snapper 7800849 Specifications

General

Brand	Snapper
Model	7800849
Category	Lawn Mower
Language	English
