Manual No.
710616722" STEEL DECK WALK BEHIND
SERIES 20
19
Grass Bag & Adapter Group
Part No Descri
tionItem Qty
1 ---- 1 USE 7600176 Grass Bag Assembly, W/Slider, 10.75” W, 26” L, No Graphics (Was 7103205)
2 7050711YP 1 ASSEMBLY, Slider
3 7042489AYP 1 WELDMENT, Bag Connector
4 7019247YP 1 WIRE, Rear Bag
5 7600117YP 1 KIT, Bag Adapter Assembly, W/pulley (Includes items 6 - 13) (Was 7058037)
6 ---- 1 USE 7600117, Bag Adapter (Was 7047081)
7 7047082AYP 1 BRACKET, Rope Pulley
8 703570 1 SCREW, 5/16-18 X 1.25, Torx Pan Head, GR 5, Zinc/Clear (Was 7091984 or 80004616)
9 703973 1 BUSHING, Flanged, .381 x .625 x .62, Metal, CZ/CL (Was 7012306 or 80005378)
10 7024228SM 1 PULLEY, Nylon, .75 ID, 1.3 OD
11 690272MA 1 NUT, 5/16-18, Serated Lock Flange, GR5, Zinc/Clear (Was 7091601 or 80002728)
12 703942 3 WASHER, 5/32 Flat, ZC/CL (Was 7072107 or 80005393)
13 704032 3 RIVET, 3/16 x .344, Truss HD, ZC/CL (Was 7013860 or 80005709)
14 7024340SM 1 SPACER, .375 OD X .316 ID X .305 L
15 7101022YP 2 KNOB, Fluted (5/16-18 thread) on side chute
16 703297 2 RETAINER, 5/16 X .625, Push Nut, GR 5, Zinc/Clear (Was 028X64MA, 5025498, 7011791,
720372 or 80002734)
17 703936 2 WASHER, .325 ID X .850 OD X .041 Thk, Internal External Lock, Type A, ZC/CL (Was 7090189
or 80005386)
17 703350 1 WASHER, 5/16, Flat SAE, Zinc/Clear (Was 7091076, 7091088 or 80004405)
18 704001 1 NUT, 5/16-18 Large Flange Center Lock, ZC/CL (Was 7090951 or 80005593)
19 703185 2 BOLT, 5/16-18 x 3/4, Carriage, Short Neck, G5, Zinc/Clear (Was 7091508 or 80004072)
