Not for

Reproduction

Footnotes:

Manual No.

710616722" STEEL DECK WALK BEHIND

SERIES 20

Wheels, Brackets & Latches

Part No Descri

tionItem Qty

0010 703964 6 WASHER, 7/16” ID, 1” OD, .060 Thk, Flat, ZC/CL (Was 7031961 or 80005597)

0020 7600180YP 1 KIT, Front Wheel Arm Assembly, RH (Was 7051886)

0020-20 7012325YP 2 LATCH, Height

0020-30 703839 2 BOLT, 5/16-18 X .750, Hex Washer Head Shoulder, Zinc/Clear (Was 7015761 or 80004422)

0020-50 7031017YP 1 WHEEL ARM, Front, Round Hole, RH, Clear

0030 7054246YP 1 ASSEMBLY, Wheel Arm, Long, RR (Was 7054230YP)

0030-10 703840 2 BOLT, 5/16-18 X 1.0, Hex Washer Head .435 Dia. Shoulder, ZC/CL (Was 7011078 or

80004423)

0030-20 703297 4 RETAINER, 5/16 X .625, Push Nut, GR 5, Zinc/Clear (Was 1921982, 3031796 or 80003523)

0030-30 7012312YP 2 BEARING, 9/16” ID

0030-50 7032722YP 1 ARM, Wheel, Right Rear, Zinc/Clear

0030-60 7035717YP 2 LATCH, Height Adjusting, (long)

0030-70 703967 6 SCREW, #10-32 x 3/8, Torx Hex Washer Head Self-Tap, ZC/CL (Was 7091012 or 80005604)

0030-90 7103793YP 4 GRIP, Height Latch, Black (Was 7100633)

0040 7054247YP 1 ASSEMBLY, Wheel Arm, Left Rear, Long (Was 7054231YP)

0040-50 7032723YP 1 ARM, Wheel, Left Rear, Zinc/Clear

0050 703348 4 NUT, 7/16-20, Hex Jam Center Lock, GR B, Zinc/Clear (Was 7090377 or 80004407)

0060 690272MA 4 NUT, 5/16-18, Serated Lock Flange, GR5, Zinc/Clear (Was 7091601 or 80002728)

0070 7021119YP 1 AXLE, V21

0080 7031960YP 2 HUBCAP, Rear

0090 7031121YP 4 HUBCAP, Front

0100 7600179YP 1 ASSEMBLY, Front Wheel Arm, LH (Was 7051885)

0100-50 7031016YP 1 WHEEL ARM, L.H. Front (Square Hole)

0110 7035727YP 2 WHEEL, 8 x 1.75 - Steel - D - Gray

---- 7011125YP 4 BEARING, 7/16” ID, Ball, Front Wheel (Not Shown)

0120 7035726YP 2 WHEEL, 10 x 1.75, Steel-D, (Self Propelled) - Gray
