5
#5
#2
#7
#18
#8
#9
#14
#10
#3
#12
#1
#17
#16
#6
#11
#4
#13
TITAN PARTS LIST
Part #1 – LEFT SIDE
Part #2 – TOP
Part #3 – RIGHT SIDE
Part #4 – BOTTOM
Part #5 – BACK
Part #6 – DOOR FRAME
Part #7 – TOP INTERIOR PANEL
Part #8 – LEFT INTERIOR PANEL
Part #9 – RIGHT INTERIOR PANEL
Part #10 – BOTTOM INTERIOR PANEL
Part #11 – DOOR HANDLE SPOKES
Part #12 – DOOR
Part #13 – DIVIDER
(optional)
Part #14 – GUN RACK DIVIDER TOP (optional)
Part #15 – SHELF HARDWARE (not pictured)
Part #16 – LOWER SHELF (optional)
Part #17 – LOWER SHELF (optional)
Part #18 – UPPER SHELF
Part #19 – HARDWARE (not pictured)
Part #20 – FULL GUN RACK (not pictured)
