Snell CLS.5 - Specifications

2
Specifications CLS.5
Frequency Response (
±
2dB) 80Hz–20kHz, -6dB @ 60Hz
Recommended Amplifier Power 15–150 watts (above 80Hz)
Nominal Impedance 8 ohms
Sensitivity [1 watt (2.83v) at 1m] 89dB SPL
Tweeter (video-shielded) 1-inch (25mm) black-anodized aluminum dome
with neodymium magnet structure
Bass Unit (video-shielded) 5
1
¼
4
-inch (135mm) cast aluminum basket.
Copolymer cone and butyl rubber surround resist
environmental extremes.
Grille Perforated aluminum (47% open), powder-coated
paint
Dimensions (HxWxD) 10
1
¼
2
x 6
5
¼
16
x 8
1
¼
16
"
26.7cm x 16cm x 20.5cm
Weight/each 11 lbs (5kg)
Finish Black or white powder-coated paint
SPECIFICATIONS
Aluminum die-cast enclosure
5
1
¼
4
-inch video-shielded bass unit
Hand-tuned crossover
1-inch neodymium magnet tweeter
Highly open perforated
metal grille
