Snell J7 - Specifications

2
SPECIFICATIONS
Frequency Response (±3dB)
Recommended Amplifier
Nominal Impedance
Sensitivity (2.83v at 1m)
Tweeter (video shielded)
Bass Driver (video shielded)
Crossover Point
Grille
Dimensions
(HxWxD)
Shipping Weight
Finish
* Custom paint and grilles are available for an extra charge
J7
40 Hz–20 kHz
100–300 watts
8 ohms
88dB SPL
1” (27mm) SEAS silk dome
6
1
/2-inch (165mm) SEAS treated paper cone,
5mm excursion
2.0 kHz
Perforated metal
16 x 8 x 13 inches
(406 x 203 x 330mm)
32 lbs (14.5kg) / each
Black, Cherry,
others to special order
J7
