SPECIFICATIONS SR7
Frequency Range (-6dB) 65–20,000Hz
Frequency Response (±3dB) 80–20,000Hz
Recommended Amplifier Power 20–150 watt
Nominal Impedance 6 ohms
Sensitivity (2.83v at 1m) 88dB, speaker in half-space, wall-mounted
High-Frequency Drivers 1-inch (25mm) soft dome tweeter
with neodymium magnet structure.
Midrange Frequency Drivers Dual 2.5” (64mm) extended-range units with sealed
enclosures
Bass Unit 5.25” (133mm) omnidirectional unit with
a stamped steel basket and treated paper cone
Crossover Frequency 400Hz, 3kHz
Cabinet Construction High-density fiberboard
Grilles Perforated steel
Flush-Mounting Bracket Interlocking hangers
Included Hardware Sixteen (16)
1
⁄8” diameter toggle wings with 2-inch
machine screws
Sixteen (16) 2” #6 self-tapping screws
Two (2) mounting templates
Dimensions (HxWxD) 10.4 x 11.75 x 5.625” (264.2 x 298.5 x 142.9mm)
Weight/each 12 lbs ea (5.3kg)
Finish Hand-sanded, hand-painted Black or White paint with
black or white aluminum endcaps
Operation Surround mode controlled by a toggle switch
(Diffuse=Up; Direct=Down)
INTRODUCTION
3
A good surround speaker adds realism to
today’s multichannel audio systems by expand-
ing the stereo spread beyond the front speak-
ers or by creating an all-enveloping sound
field, but not necessarily both. Snell’s new SR7
surround speaker surpasses previous surround
speakers by offering the easily switchable
choice between a diffuse field or a direct field
response.
For Use with All Home Theater Formats
The SR7’s meet the demanding sonic require-
ments of digital 5.1/7.1 channel formats as
well as the demanding specifications of THX
Ultra 2.
The SR7 allows you to switch, using multiple
drivers and a sophisticated acoustical matrix-
ing
technique, between an outward-firing
direct sound field balanced to precisely
match our Snell front-channel speakers or a
”fore and aft” firing diffuse sound field.
Designed to match all Series 7 products.
An elegant, tapered enclosure packages
all of these features in a pleasing on-wall
cabinet.
