EN - Installation and operation manual
SFD1000MM / SFD500MM / SF1000MM /SF500MM
Thank you for buying this fantastic Snowfall™ product.To take full advantage of all possibilities, it is recommended to read
these operating instructions very carefully.
Contents of the package
The Snowfall™ box contains the following components:
• 5x/10x Snowfall™ tubes (500/1000mm)
• 1x Snowfall™ 12V transformer with a Snowfall™ cable with a connector* and power cable with grounding
• 1x Snowfall™ End Plug
• Transformer
* : Type 220/240V~12V. Insulated and suited for outdoor use and for maximum 20m of Snowfall™ tubes type SF500MM/SF1000MM/SFD500MM/SFD1000MM.
F
eatures
Each Snowfall™ tube:
• consists of 60/120/240 high efciency LEDs with high brightness grade
• is suited for indoor and outdoor use (IP44 and IP64 approved)
• has a life span of 50.000 to 100.000 hours
• has low power consumption.
The transformer can be directly connected to the 220/240V main supply.
Perfect for use in retail stores, commercial displays, decorative and street lighting and outdoor decoration.
Some important instructions
• Protect the environment! Try to recycle the packing material as much as possible.
• Keep this manual in a safe place for future consultation.
• If you sell this unit, be sure to add this installation manual.
• Don’t use near strong magnetic elds and objects carrying high voltages.
• The electrical installation should be carried out by qualied personal.
• We strongly suggest NOT opening the unit, there are no user serviceable parts inside.
• In the event of serious operating problems, stop using the unit and contact your dealer immediately.
• Keep the system out of children’s reach. This is not a toy.
Installation
• Fasten all tubes, connecting cables and connectors.
• The tubes are suited for outdoor applications but may not be used under water.
• They have a temperature range between -15° ~ +40° Celsius or 5° ~ 104° Fahrenheit.
• Connect the Snowfall™ cables to each other by using the supplied connectors. Make sure to tighten the plastic
fastening ring well. Attention: Please make sure that the polarization is correct. Connect male and female in the
right order! Look carefully for the slip in the connectors!
• Connect the transformer to the 220/240V mains supply.
• After carefully carrying out all the above mentioned steps, you can switch on the system.
• Enjoy your Snowfall™ product.
Adapter End PlugTube
IMPORTANT!
Use Hang up cables to hang the tubes. Do
not hang them by the electricity wires!
