SECTION 4
NORMAL PROCEDURES
D.G.A.C. Approved
T B M
700 PILOT’S INFORMATION MANUAL
Back to
Contents
Page 4.4.1
Rev. 3
4.4 – AMPLIFIED PROCEDURES
PREFLIGHT INSPECTION
A – INSIDE INSPECTIONS
Cockpit
I
– CRASH lever UP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 – ELECTRIC POWER panel
–”SOURCE” selector OFF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
–”GENERATOR” selector MAIN. . . . . . . . . . . . . . . . . . . . . . . . . . .
2 – ENGINE START panel
–”IGNITION” switch AUTO or OFF. . . . . . . . . . . . . . . . . . . . . . . .
The ”IGNITION” switch is normally selected to AUTO. This
ensures ignition, whenever the ”STARTER” switch is set to ON.
–”STARTER” switch OFF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If not, starter is going to operate as soon as ”SOURCE” selector
is moved to BAT or GPU (if connected).
3 – EXT LIGHTS panel
– All switches OFF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 – GYRO INST panel
– All switches OFF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 – Breakers panel
– All breakers ENGAGED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 – DE ICE SYSTEM panel
– All switches OFF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7 – Landing gear control DN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
