SECTION 2
LIMITATIONS
D.G.A.C. Approved
T B M
700 PILOT’S INFORMATION MANUAL
Back to
Contents
Page 2.3.1
Rev. 9
2.3 – POWER PLANT LIMITATIONS
ENGINE
Number of engines : 1
Engine manufacturer : PRATT & WHITNEY CANADA
Engine model number : PT6A – 64
Engine operating limits for takeoff and continous operations :
Maximum power :
– 700 SHP : MAX TRQ 100 % at Np = 2000 RPM
MAX TRQ 110 % at Np = 1800 RPM
Maximum power :
– Ng : 104.1 %
– Np : 2000 RPM
ITT :
– Anytime during engine operation :
. continuous : 800°C
– During start : 870°C for 20 seconds max.
1000°C for 5 seconds max.
CAUTION
WHEN NORMALLY OPERATING, REFER TO CHAPTER 5.7
”ENGINE OPERATION” TABLES
OIL
CAUTION
DO NOT MIX DIFFERENT BRANDS OR TYPES OF OIL
Maximum oil temperature : 104 °C
Oil pressure :
Minimum : 60 psi
Maximum : 135 psi
Oil capacity :
System total capacity : 12.7 Quarts (12 Litres) (Oil cooler included)
Usable capacity : 6 Quarts (5.7 Litres)
