T B M
PILOT’S INFORMATION MANUAL 700
SECTION 7
DESCRIPTION
Back to
Contents
Page 7.3.16
Rev. 6
MASTER
WARNING
General warning
upon illumination of red warning light
MASTER General warning
MASTER
CAUTION
General warning
upon illumination of amber warning light
ITT Inter turbine temperature ≥ 800°C
OIL PRESS Engine oil low pressure ≤ 4.1 bar (60 psi)
STARTER Starter generator running (flashing)
IGNITION Ignition exciter running
PARK BRAKE Parking brake applied
FIRE Engine compartment fire (temperature greater than 200°C)
(if installed)
BLEED TEMP Conditioned air temperature at outlet cooling turbine
compressor ≥ 232°C
BLEED OFF Pressure regulator / shut–off closed
CAB PRESS Cabin altitude ≥ 10000 ft or ∆P ≥ 423 mbar (6.2 psi)
DOOR Passenger’s door, not closed and locked
FLAPS Dissymmetry between L.H. and R.H. flaps
OXYGEN One oxygen generator has been activated
PITOT 1 Pitot tube Nr 1 not heated
PITOT 2 Pitot tube Nr 2 not heated
STALL HTR Stall warning not heated
INERT SEP Inertial separator ”INERT SEP” control switch set to ”ON”
VACUUM LO Vacuum generator, vacuum ≤ 3.75 in.Hg
BAT OVHT Battery abnormal temperature
BAT OFF Battery unconnected and main distribution bar supplied by
another generator
MAIN GEN Starter generator unconnected
LO VOLT Battery, voltage ≤ 26 Volts
G P U GPU receptacle door not closed
FUEL OFF Fuel tank selectors set to ”OFF”
FUEL PRESS Fuel pressure ≤10 psi
AUX BP ON Electric fuel pump, running (manual or automatic mode)
FUEL L. LO L.H. fuel tank low level, fuel quantity ≤ 34.6 l (9.1 us gal)
FUEL R. LO R.H. fuel tank low level, fuel quantity ≤ 34.6 l (9.1 us gal)
AUTO SEL Fuel timer OFF or out of service
BRIGHT Indicator lights brightness selector, day position
DIM Indicator lights brightness selector, night position
TEST 1 & 2 Lights test switch (double check)
Figure 7.3.8 (1/2) – ADVISORY PANEL AND GENERAL
ALARMS WARNING LIGHTS
