T B M
PILOT’S INFORMATION MANUAL 700
SECTION 7
DESCRIPTION
Back to
Contents
Page 7.3.26
Rev. 5
Figure 7.3.11A (1/2) – SEATS
Valid S / N 24, 26, 27, 29 to 32, 34, 36 to 9999, plus
airplanes equipped as
a retrofit with modification Nr MOD 70–019–25
1) Front passenger’s seat
2) L. H. pilot’s seat
3) R. H. intermediate passenger’s seat (back to flight direction)
4) L. H. intermediate passenger’s seat (back to flight direction)
5) R. H. rear passenger’s seat
6) L. H. rear passenger’s seat
7) Front seat(s) longitudinal shift control
8) Oxygen masks (2) drawer (intermediate seats)
9) Front seat(s) height control
10) Front seat(s) back–rest tilt control
11) Drawer for pilot’s piddle pak (if installed)
(front side : new bags, rear side : used bags)
12) Intermediate seat(s) back–rest tilt control
13) Rear bench seat(s) back–rest tilt control
Rear bench
NOTE :
To have access to the aft baggage compartment, pull forwards the
back–rest of rear bench seat(s).
