SOCATA TBM 700 - Page 496

TBM 700B
T B M
PILOT’S INFORMATION MANUAL 700
SECTION 7
DESCRIPTION
Back to
Contents
Page 7.3.28
Rev. 7
Figure 7.3.11B (1/2) – SEATS
1) Front passenger’s seat
2) L. H. pilot’s seat
3) R. H. intermediate passenger’s seat (back to flight direction)
4) L. H. intermediate passenger’s seat (back to flight direction)
5) R. H. rear passenger’s seat
6) L. H. rear passenger’s seat
7) Front seat(s) longitudinal shift control
8) Oxygen masks (2) drawer (intermediate seats)
9) Front seat(s) height control
10) Front seat(s) back–rest tilt control
11) Drawer for pilot’s piddle pak (if installed)
(front side : new bags, rear side : used bags)
12) Intermediate seat(s) back–rest tilt control
13) Rear bench seat(s) back–rest tilt control
14) Rear bench seat L.H. seat tilt control
NOTE :
To have access to the aft baggage compartment, pull forwards the
back–rest of rear bench seat L.H. seat, then pull forwards control (Item 14)
to tilt L.H. seat assembly forwards.
If necessary, pull forwards the back–rest of rear bench seat R.H. seat.
Rear bench
