SOCATA TBM 700 - Page 566

T B M
PILOT’S INFORMATION MANUAL 700
SECTION 7
DESCRIPTION
Back to
Contents
Page 7.8.6
Rev. 7
Figure 7.8.3 (1/2) – CIRCUIT BREAKER PANEL (Typical arrangement)
ADVISORY 1 Visual warn. protec.
ADVISORY 2 Visual warn. protec.
AUDIO Audio warnings protec.
WARN
AP / TRIMS AP & trims general protec.
RUD TRIM Rudder trim protec.
AIL TRIM Aileron trim protec.
PITCH TRIM Pitch trim protec.
FLAPS Flaps protec.
LDG GR Landing gear general protec.
ESS BUS TIE Essential bus NORM &
EMER switch
PITOT 1 HTR Pitot 1 deicing protec.
PITOT 2 & Pitot 2 and stall warning
STALL HTR deicing protec.
INERT SEP Inertial separator protec.
LW/S DE ICE L.H. windshield deicing
protec.
RW/S DE ICE R.H. windshield deicing
protec.
PROP DE ICE Propeller deicing protec.
AIRFRAME Empennage and wing
DE ICE Leading edges deicing
protec.
ICE LIGHT L.H. wing leading edge
lighting protec.
L LDG L.H. landing light protec.
TAXI Taxi light protec.
R LDG R.H. landing light protec.
NAV Navigation lights protec.
STROBE Strobe lights protec.
CABIN Passenger’s reading
lamps protec.
ACCESS FWD dome light, cabin,
baggage compartment
bottom & access door
lighting protec.
INSTR Instruments light. protec.
PANEL NORM Instrument panel normal
lighting protec.
PANEL EMER Instrument panel emer–
gency lighting protec.
FUEL GAGE 1 L.H gage protec.
FUEL GAGE 2 R.H gage protec.
FUEL SEL Timer protec.
AUX BP Fuel pump protec.
MEMORY Stop watch and
& CLOCK flowmeter protec.
ENGINE Power plant cont. protec. :
INDIC 1 Oil temp. & pres.,
torque, propeller
ENGINE Power plant cont. protec. :
INDIC 2 Ng, flowmeter & ITT
IGNIT Power plant ignit. protec.
FLAPS SIG Flaps signalization protec.
LDG GR Landing gear control
CONT protec.
LDG GR Landing gear signalization
SIG protec.
AP DISC Trim and AP cont. protec.
AP ALERT Trim and AP audio
signalization protec.
AP ALT SEL Altitude selector protec.
ST/BY G Standby gyro protec.
ADI 1 ADI Nr 1 protec.
TURN COORDTurn coordinator protec.
HSI RMI HSI & RMI protec.
ADI 2 ADI Nr 2 protec.
PHONES Reception line protec.
SPKR Loudspeaker ligne protec.
COM 1 VHF 1 protec.
NAV 1 NAV 1 radio protec.
COM
2
VHF 2 & NAV 2 radio
NAV protec.
ENCOD Encoding altimeter
ALTI protec.
XPDR Transponder protec.
RADIO FAN Radio fan protec. +
radio master (if installed)
ADF ADF protec.
DME DME protec.
MKR MKR protec.
STORM WSR Radar+Stormscope
protec.
WSR Weather radar protec.
LRN GC LORAN long range
navigation protec.
RADIO ALTI RADIO ALTI protec.
RMI 2 RMI 2 protec.
ESS BUS 1 Essential bus 1 circuit
protec.
ESS BUS 2 Essential bus 2 circuit
protec.
CABIN Cabin air bleed valve
BLEED protec.
CABIN Cabin temperature valve
TEMP protec.
FAN Ground fan protec.
TBM 700A from S/N 1 to 10
