PROTECTION – SAFETY (Figure 7.8.5)
The electrical power center provides systems protection in case of :
– overvoltage coming from the starter generator, the stand–by generator or
the ground power receptacle
– short–circuit in starter generator feeder
– starter generator undervoltage
In case of disconnection of starter generator or stand–by generator following
a failure, it is possible to re–activate the system by pressing on ”MAIN” or
”ST–BY” knob of ”GENERATOR RESET”.
A crash lever located on upper panel center part allows isolating
simultaneously ”BUS BAT” bar and setting to ”OFF”, ”SOURCE” and
”GENERATOR” selectors when lowered. All bus bars are isolated from
generators.
