Figure 7.9.1 (1/2) – AIR CONDITIONING
1) Overheat switch
2) Cooling turbine
3) Hot air – cold air mixer
4) Water separator
5) Temperature control valve
6) Pressure regulator of temperature control valve
7) Check–valve
8) Temperature control sensor
9) Cabin emergency air inlet
10) Defogging outlets
11) Adjustable air outlets
12) Air conditioning fan
13) Distribution box
14) Warning lights box
15) Microswitch (airplane on ground)
16) Pressure regulator and shutoff valve
17) Flow limiting venturi
18) Ground cooling fan
19) Spray nozzle aspirator
20) Heat exchanger
