T B M
PILOT’S INFORMATION MANUAL 700
SECTION 2
LIMITATIONS
D.G.A.C. Approved
Back to
Contents
Page 2.9.2
Rev. 2
(2) Calibration chart on compass and on windshield post
For N 30 60 E 120 150
Steer
For S 210 240 W 300 330
Steer
DATE : RADIO ON
(3) On rear baggage compartment bottom bulkhead (pressurized)
100 kg – 220 lbs MAXIMUM
IT IS THE PILOT’S RESPONSIBILITY TO
CHECK THAT ALL THE BAGGAGES ARE
PROPERLY SECURED
FOR LOADING INSTRUCTIONS
SEE ”WEIGHT AND BALANCE DATA”
IN PILOT’S OPERATING HANDBOOK
(4) On FWD baggage compartment door frame (non pressurized)
50 kg – 110 lbs MAXIMUM
FOR LOADING INSTRUCTIONS
SEE ”WEIGHT AND BALANCE DATA”
IN PILOT’S OPERATING HANDBOOK
WARNING
TURN L AND R WINDSHIELD
DE–ICE OFF BEFORE
COMPASS READING
