Technical manual Sylax DN 25-350 mm
uksylax25_350 - Updated 20/09/20166
(1) Pneumatic actuator only
Actuations
HAND LEVER
PNEUMATIC
ACTUATOR
ELECTRIC
ACTUATOR
• 1 or 2 mechanical limit switch
For other options, please
consult us.
• Switchbox :
. mechanical
. inductive
. inductive + solenoid valve
. mechanical + solenoid valve
• Inductive limit switch
• Positioners (1)
. BURKERT 1067
• Remote control +
emergency hand
wheel
• Auma • Bernard
• Socla
• Belimo
• Rotork
• Notched hand
lever polyamide
(PCX)
GEAR BOX
• Manual gearbox in
cast iron
• Adjustable ductile iron
hand lever (PRF)
• Notched ductile iron hand
lever (PCF)
ASSEMBLY LEVEL 1 ASSEMBLY LEVEL 2
• Socla
Find below the different standard assembly combinations.
For any other information, please ask our technical Department.
