socomec DIRIS Ap - Page 5

SOCOMEC - Réf. : 875 518 B-GB 5
DIRIS 343 A
2
Fix the module in one of the four positions.
OUT1
OUT2
OUT3
OUT4
5678
+-+-
5678
+-+-
DIRIS 436 B
4
When using the four outputs, the two modules must be installed in the
two left-hand positions as shown.
5678
+-+-
OUT1
OUT2
DIRIS 435 A
3
