socomec DMS 210 User Manual

2.2 Technical features DMS 210
Technical features
Unit of
measurement
Value
Energy per stroke J
500
Maximum frequency s/min
1200
Maximum oil flow l/min
40 – 55
Maximum working pressure bar
120
Maximum exhaust back pressure bar
20 - 30
Accumulator charging pressure bar
45
Calibration pressure of the hydraulic system maximum valve bar
180
Hammer weight in working conditions Kg
210
Tool weight Kg
18
Pin retainer tool weight Kg
0,7
Pressure line pipe diameter (EN 856 - 4SP) G
1/2 “
Return line pipe diameter (EN 853 - 2SN) G
1/2 “
Tool diameter mm
62
Hammer height with tool without adapting plate mm
1200
Maximum length of the tool inner guide (L) mm
235
Maximum diameter in front and back the tool bushings mm
65,5
Maximum oil temperature in the tank °C
80
Maximum absorbed power Kw
12
Excavator weight T
2.8 - 3.8
TECHNICAL FEATURES
8
Page
of
33
2
