socomec DMS 95/2 - Accumulator Details

!
2.2.1 Tightening values:
Component denomination
Unit of
measurement
Value
Accumulator long screw Nm
80
Accumulator short screw Nm
80
2.3 The accumulator
DMS 95/2 ACCUMULATOR SCREWS
V.L = Long screws
RUBBER HOSES CONNECTION
It’s necessary to unscrew the long screws in order to remove the
accumulator from the monoblock.
You will find here below the accumulator details with the long screws to be
unscrewed highlighted.
HOSES CONNECTION
TECHNICAL FEATURES
