Soehnle LUCCA - Specifications; Troubleshooting

7
EN
D. Troubleshooting
Symptom Error Solution
No
mist
Power supply unit not proper-
ly connected
Insert power supply unit
into power outlet and
device
Not enough water in the
water tank
Fill up to the maximum
water level indicator
Too much water in the water
tank
Pour out water until it
reaches the maximum
water level indicator
The upper part is plugged up
by a water lm or something
else
Use cloth to clean
1. Remove remaining water.
Do not use ventilation ope-
ning!
2. Use cloth and cotton swabs to
wipe out water tank.
3. Do not use strong or abrasive
cleaning agents.
C. Specifications
Dimensions: 96x124x168 mm
Rated voltage: 24V⎓
Nominal output: 10 W
Water volume: 80ml
Power supply unit:
Modell: K13S240050G
Primary:
100-240V~50/60Hz 0.5A
Secondary:
24V⎓ 500 mA ta=40°C
Modell: NLB050240W1U3
Primary:
100-240V~50/60Hz 0.4A Max
Secondary:
24V⎓ 500 mA ta=40°C
