3.2 Montage
Assemble your SO3
1. Press the rear fender down and separate the hook from the fender buckle. Pull up the Frontbar until you hear a clicking sound indicating that the folding system has been locked in place. At
the same time the safety latch will also be locked in place.
2. Put the handlebar into the Frontbar and use the wrench to tighten the screw.
3. Test the functionality of your SO3 after the assembly.
Folding / Putting away your SO3
Before folding the SO3, make sure that it is powered off. Fold up the kickstand and hold the Frontbar while you pull out the right safety pin. Rotate it in
clockwise direction, then pull the lever. Proceed to fold down the Frontbar and fix it to the fender buckle using the hook. The SO3 has been successfully
folded once you hear a clicking sound.
Instructions on adjusting the dics brake
If the brakes are too tight, use a 4mm Allen wrench to loosen the screw of the pressure plate by turning anticlockwise. Shorten the length of the brake wire
to loosen the brakes, then tighten the screw again. If the brakes are too loose, loosen the screw and pull the brake wire to extend the wire, then tighten the
screw again.
