16 | P a g e
Add the extension tube onto the extension tube attachment that was just mounted and screw in six new
screws to attach, see Figure 17.
Figure 17: Mount and secure extension tube.
Re-attach the top mounting plate to the top of the extension tube and attach with six 10-32 x 1/2-inch
BHCSs (Figure 18).
Figure 18: Re-attach and secure top mounting plate.
