Sojag 852897 - Hardware Kit

3
© Sojag inc. 2015
HARDWARE KIT TROUSSE DE QUINCAILLERIE
NOTE:
Parts not shown to actual size and not to scale.
NOTE :
Le matériel n’est pas représenté à l’échelle.
Z1
Y
Y1
Z
W
X2
X30
X10
X2
X8
U
X58
U1
X20
V
X16
V1
X3
X
X24
Item Description Qty
U Screw M6X16 58
U1 Screw M6X12 20
V Screw M6X20 16
V1 Screw M6X30 3
W Screw M6X12 (D12x20) 8
X Screw St4x15 24
X1 Screw St4x10 20
X2 Screw M6X12 8
Y Cap Nut 30
Y1 Screw M6x12 10
Z Allen Key 2
Z1 Wrench 2
Pièce Description Qté
U Vis M6X16 58
U1 Vis M6X12 20
V Vis M6X20 16
V1 Vis M6X30 3
W Vis M6X12 (D12x20) 8
X Vis St4x15 24
X1 Vis St4x10 20
X2 Vis M6X12 8
Y Écrou borgne 30
Y1 Vis M6x12 10
Z Clé hexagonale 2
Z1 Clé plate 2
