Solar-Log Inverter - 48 Omnik; 48.1 Omnik

143
Omnik
Omnik
48 Omnik
48�1 Omnik
Easy Installation Termination Addressing Sensors RS485 Meters RS485 Interface
No
No
Automatic
No No RS422
Overview
•
Integrated interface
•
Where to connect: RJ45 socket on the outside of the inverter
•
4-pin cable – only on RS485/422 B/C connection of the Solar-Log™
•
Communication address does not have to be assigned
Note
The order in which the inverters are displayed in the Solar-Log™ after detection is random.
We strongly recommend that you change the order of the inverters immediately after de-
tection at startup in the Configuration|Device|Configuration|Order menu box.
The inverters can be identified using the displayed serial number.
•
Installation steps
• Switch off the inverters and Solar-Log™
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
Connect inverters to the Solar-Log™
The wiring is done using a
•
self-made cable connection with RS485 data cable and terminal block connector.
Caution
Risk of damage to the unit!
The Solar-Log™ also has an RJ45 socket, which must never be connected to the RJ45
socket on the inverter.
► OnlyconnectinvertersviatheRS485/422B/CSolar-Log™interface.
