1. GENERAL INFORMATION AND SAFETY INSTRUCTIONS
1.1. Purpose of the device
GNC type hobs are hobs for in-built installation, designed for preparation of dishes
and use in households. The gas burners are equipped
with temperature sensors, which assure maximum user safety and automatic, precise
operations. GNC belongs to a generation of gas hobs, whose burners are controlled
electronically and the device has
sensor-based control. The hob is designed for in-built installation in the countertop of a
single kitchen cabinet or in a composite countertop.
1.2. Technical specifications of the hob
Parameter
Unit
Value
Type and group of supplied
gas
2E
2Lw
2Ls
2L
3B/P
3P
3P
G20
G27
G2,350
G25
G30
G31
G31
Nominal connection
pressures
mbar
20
20
13
25
37
37
30
Thermal power of all 4
burners
kW
7.4
Gas stream of all 4 burners
g/h
~740
(This value applies only to liquefied gases)
Power of individual burners
Large burner
kW
2.8
Nozzle diameter
mm
1.31
1.49
1.90
1.35
0.85
0.90
0.90
Medium burners
kW
1.8
Nozzle diameter
mm
1.05
1.25
1.49
1.05
0.70
0.75
0.79
Small burner
kW
1.0
Nozzle diameter
mm
0.79
0.90
1.05
0.85
0.50
0.55
0.57
Gas connection
on the underside of the hob with an R1/2 internal pipe thread
Voltage and power supply
230 V/50 Hz -12V DC 4.5 A 60 VA
Protection rating
IP40
Device class
II
Hob dimensions
(W x D x H)
mm
580 x 500 x 67 (the dimensions include the protruding cover for
engines), grid above the hob - 55
WARNING!
Please bear in mind that stepper motors placed under the hob's glass plate control the size of
the flame and may be audible during adjustments. When the burner is turned on and the gas
ignited, a regular sound (knocking) can be heard. These are normal phenomena
and sounds of a working hob.
