Model AVS30 micro 110V 230V
Current (Amps) 30 30
Nominal voltage(V) 110 230
Wait time (mins) 10 secs to 10mins+manual 10 secs to 10mins+manual
Under-voltage disconnect(V) 75-110 150-230
Over-voltage disconnect(V) 110-150+off 230-300+off
Hysteresis(V) 3-5 3-5
Socket type direct via brass screw terminal direct via brass screw terminal
Fused plug N/A N/A
RFI protection No No
Transient suppression Yes >6.5kA Yes >6.5kA
Spike protection(J) 80 160
SPECIFICATIONS
CONNECTION:
CAUTION: IF THE AVS30 IS ALREADY WIRED, MAKE SURE IT IS DISCONNECTED FROM
THE MAINS BEFORE YOU DO ANY OF THE FOLLOWING;
1. Remove the bottom cover to obtain access to connection terminals. To remove
bottom cover remove the two white caps and then undo the two screws.
2. Remove the two cable glands and then re-insert them so that the cable gland
is external.
3. Insert cable from the mains supply through the cable glands of the AVS30 and
connect to the connector terminals. (Refer to connection terminals layout diagram
on next page).
4. Insert cable to appliance through the cord grip bush and connect to the connector
terminals.
5.
Tighten the cord grip bushes and return the front cover and two screws and screw caps.
PLEASE ENSURE NOT TO TIGHTEN CONNECTION TERMINALS EXCESSIVELY.
NOTES:
• In the upper compartment of the AVS30, you will find a fuse (see diagram overleaf).
The fuse is not for the load. It is a spike protection fuse. Replace if it gets damaged.
(0.5A Anti Surge). To gain access to the upper compartment, ENSURE THAT THE
AVS30 IS NOT CONNECTED TO THE MAINS. Remove the screws from the back.
• The AVS30 must be mounted securely on a wall. Place it over one screw at the top
and then use the two mounting holes in the terminal compartment.
• The supply to the AVS30 must be fitted with a 30A HBC fuse or less.
