Installing the stainless-steel handle
Your wine / beverage cooler includes a stainless-steel handle. To install the handle please follow the below
instructions:
1. Pull away the door gasket in the area where the handle is to be installed on the left side as shown below in
Illustration # 1. The gasket is easily displaced by hand, no tools are necessary.
2. Align the handle with the screws installed. Tighten the screws using a Phillips head screwdriver until the
handle sets both flush and secured tightly against the door frame. (DO NOT over tighten as this will cause
damage to the handle assembly).
3. Replace the door gasket to its original position.
Illustration # 1 Illustration # 2
