Solo 330 - 460 Tester: Adjusting Test Head Angle; 460 Tester: Power On & Detector Positioning

8
Power on the unit
by pressing the red
button on the side
of the tester head.
Raise the Solo 460
and position the
detector into the
clear cup at the top
of the unit, ensuring
the heat output
duct aligns with the
thermistor(s) in the
detector. The green
LED will ash faster.
Adjust the angle by
pressing down on
the red lever.
Release the lever at
the desired angle to
lock the tester head
in position.
3
2
