Solo 432 - Technical Specifications and Maintenance; Technical Specifications; Maintenance Schedule

20
Maintenance Chart
before every use
Carburetor
Airfilter
Spark pug
Cooling Air
Inlet
Cylinder fins
Fuel tank
All accessible screws
(except carburetor
mixture screws)
Operational control handle
Complete maschine
check idling speed
clean
replace
re-adjust electrodes
replace
clean
clean
clean
re-tighten
check all functions
visual check
clean
daily
weekly
after 5 hours
after 50 hours
as required
X
X
X
X
X
X
X
1)
X
X
X
X
X
X
X
X
X
Technical Specifications Motorized Pressure Sprayer 432
1.) Data provided is
based on equal parts for
operational conditions
in idling mode and in
full speed mode.
.
This may vary
depending on order or
supply requirements
and availability
Spray Nozzle
• Generally (but this may vary depending on the order requirements) an adjustable nozzle is supplied with the sprayer.
• This nozzle allows the following output: Set for fine spray approx. 0.8 l/min at ….bar. Set for stream and for distance approx. 1.5 l/min. at ….bar.
Engine type SOLO single cylinder two cycle engine
Engine capacity 25cc
Bore / Stroke 33 / 30 mm
Engine power in kW at 1/min 0.75 / 6500
Average engine idling speed 1/min 2800
Carburetor all-position diaphragm carburetor with
primer and integrated fuel pump
Ignition
electronically controlled and maintenance free magneto ignition
Fuel tank capacity , litre 0.3
Capacity of spray tank, nominal litre 20
Measurements without spray wand height, width, depth, cm 67 / 38 / 26
Weight, kg 6.5
Work site related noise emission value
LP to ISO 7182
1.)
dB (A) 82
Sound pressure level LW dB/A to
ISO 9270*, measured / guaranteed 94.2 / 95
Weighted medium value of acceleration coefficient to ISO 7505 < 2.0
Pump Piston-Diaphragm pump
Flow rate, max. 3 l/min
Operating pressure, bar 1 – 8
Spray wand brass, 500 mm
Spray nozzle adjustable nozzle *
Spray hose 10 x 3 mm
