Important Components
ENGLISH 6
7. Important Components
1. Tank lid / Filler basket with filte
r
12. Shoulder strap
–
quickcoupling
2. Fo
r
mula tank 13. Liquid tap
3. Formula outlet 14. Spray tube
4. Spark plug 15. Spray nozzle
5. Carburetor adjustment screws 16. Dosage sleeve
6. Muffle
r
17. Throttle leve
r
7. Starter handle 18. Wide-range nozzle
8.
A
ir filter cove
r
19. Stop switch
9. Fuel tank cap 20. Tank ventilation
10. Choke 21. Throttel control lock
11. Prime
r
22. Blower elbow
Fig. 1
