6 Specification and special accessories
ENGLISH 12
6 Specification and special accessories
Model 456 / 456 Pro 457
Spraying agent tank: Nominal volume ("Total Vol."
1
)
Max. fill volume ("max. Vol."
1
)
approx. 7.5 l
[1.98 gal]
approx. 5.0 l
[1.32 gal]
approx. 9.0 l
[2.38 gal]
approx. 7.0 l
[1.85 gal]
Residual volume not properly discharged by the device < 200 ml [6.8 oz]
Maximum permissible operating pressure ("P max."
1
) 3.0 bar [44 psi]
Permissible operating temperature ("T max."
1
) 0–40 °C [32–104 °F]
Spray tube (material: PVC) Length 500 mm [19.7"]
Pressure hose: Length 1,500 mm [59"]
Standard spray nozzle (red flat spray tip 04-F110): Part no. 40 74 263
Accessories: Nozzle-kit (9 different nozzles) Part no. 49 00 574
Maximum delivery ("max."
1
)
(with standard spray nozzle at 3 bar)
1.6 l/min [0.423 USgal/min]
Filter element: Mesh aperture
Part no.
0.8 mm [0.031"]
40 74 922 25
Weight: Ready for operation, spraying agent tank empty
Ready for operation, spraying agent tank filled to max.
2.6 kg [5.7 lbs]
7.6 kg [16.8 lbs]
2.8 kg [6.2 lbs]
9.8 kg [21.6 lbs]
Dimensions (without spray tube and pressure hose): Height
Width
Depth
450 mm [17.7"]
200 mm [7.9"]
200 mm [7.9"]
520 mm [20.5"]
200 mm [7.9"]
200 mm [7.9"]
1
Inscription on the spraying agent tank
