Sonart FP10764 - Controls Location

CONTROLS LOCATION
SD card
USB
MP3 CONTROL DIGITAL DISPLAY
MODE
IR
FOL
FOL- FOL+
120V
240V
POWER
AC 120V 60Hz
AC 240V 50Hz
R L
-12 +12
CLIP POWER
SPEAKER OUT
8
MIC LEVEL
BASS
LINE LEVEL
VOLUME
TREBLE
ECHO
MIN MAX
-12 +12
MIN MAX
MIN MAX
MIN MAX
AUX
LINE
INPUT
LINE
OUTPUT
MIC
INPUT
4
5
14
15
16
18
19
20
21
22
17
3
1
2
6
7
8
9
10
11
12
13
23
1. LCD screen
2. MP3 control
MODE:USB/SD/BT/FM
convertor
:Previous Song
Long press for fast rewind
:Next Song
Long press for fast forward
:Repeat one / Repeat all /
Random
:Play / Pause
FOL:Long press 3 seconds to
enter the folder option function
songs button to choose the
3. USB input
4. SD card input
5. IR Remote control receiver
6. ECHO control
7. Mic input level control
8.Line input level control
9.Master Volume control
10.Treble control
11.Bass control
12.Power LED indicator
13.Clip LED indicator
14.XLR microphone input
15.6.35mm microphone input
inputs
17.3.5mm line input
18.XLR line input
19. 6.35mm line output
20. Speaker out 8 Ohm
21.AC 120/240 Voltage
Selectable
22. ON/OFF power switch
23. Fused IEC mains inlet
