Sonicware LoFi-12 XT - Hardware Specifications

Hardware Specications
Pads 15 velocity-sensitive pads with RGB LEDs
Controllers Control knob x 5, Directional pad with 2 button controls
Display 1.5 inch OLED display
Built-in Mic Mono x 1 (Omni-directional, 94dBSPL)
Built-in Speaker Mono x 1 (1.5W 4Ohm)
Audio Inputs
INPUT L / Guitar (Switchabîe 10kOhm and 1MOhm impedanœ)
[LINE Gain] PAD: -20dB
[Hi-Z Gain] LOW: 0dB, NORMAL: +10dB, HI: *20dB
INPUT R / Dynamic Microphone
[LINE Gain] PAD: -20dB
[NIC Gain] LOW: 0dB, NORNAL: +28.8dB, HI: +50dB
Audio Outputs
STEREO LINE OUTPUTS (Max +6.5dBV]
*The above jacks are all Balanced 1/4 TRS jack Connectors
PHONES jack (stereo 3.5mm mini jack type)
USB port
micro USB Type-B
[USB Audio] USB 2.0 Full Speed, 48kHz-16bit
Input: 2 channels, Output: 2 channels
[USB MIDI]
[Mass Storage Class] USB2.0 High Speed
*For iPhone, Apple Lightning to USB Camera Adapter required separately
MIDI ports
MIDI IN (5-Pin DIN type)
MIDI OUT (5-pin DIN type)
Other connectors
SYNC IN jack (mono 3.5mm mini jack type)
SYNC OUT jack (mono 3.5mm mini jack type)
SD card slot (Standard size
*Supports SDHC cards up to 32 GB )
DC IN connector
Bottom side hole 1/4-20UNC screw for tripod
Size and weight
mount Width: 147mm I approx. 5.8 inch
Depth: 175mm I approx. 7.8 inch
Height:46mm I approx. 1.8 inch
Weight: 550g I approx.1 lbs 3.5 oz
Power supply
DC12V output AC adapter (500mA, Inner Diameter: 2.5mm, Outer Diameter:
5.5mm, Polarity: Center +)
Ni-MH AA SIZE Rechargeable Battery or Alkaline AA SIZE Dry Battery x 6
(Alkaline dry batteries life: approx. 4 hours)
*Batteries sold separately
Accessories
32GB SDHC card incl. 2,500+ samples
Power Supply Unit
Warranty
*USB cable and the other connection cables sold separately
148
