Names of parts
9
1：SYNC In/Out
Input and Output for
SYNC signals.
2：Mic
Built-in Mic with gain
knob to adjust input
volume.
3：Speaker
Built-in speaker.
4： Recording gain
knobs
Adjust input volume of
INPUT L and R.
5：Di s pl a y 6：Control knobs
Turn-and-press
type knobs for A-D
parameters on the
screen.
7：VOL knob
Adjust headphones and
speaker volume.
8：VALUE knob
Adjust master volume.
Press to open the
TEMPO MENU.
9：Auxiliary buttons
Select items displayed
at the bottom of the
screen.
10：D - p a d
7 re-trigger divisions
from 8th to 64th notes.
And menu cursor
movement and item
selection.
11：function button
Press the function
button with the other
button to switch to the
submenu.
PTN
Open the PATTERN
SELECT menu.
COPY
Copy & Paste Tracks,
Parameters or Steps.
PAD
Switch to PAD mode.
save
Open the PATTERN
SAVE menu.
song
Open the SONG SELECT
menu.
project
Open the PROJECT
MENU.
REC
Record sequence data.
Play
Play/Stop a pattern or
song.
MIX
Launch the MIXER.
MUTE
Mute the track(s).
sampling
Open the SAMPLING
page.
system
Open the SYSTEM
MENU.
ext src
Open the USB ＆ EXT IN
page.
mix tape
Open the TAPE REC
page.
12：O K
Used to conrm in
MENU.
13：C L R
Used to cancel a step
or exit from the menu
screen.
14：S T E P s
Press with the Track
Pad: Direct data entry.
Press function button
simultaneously to edit
the data.
15： Page Switches
Select the page(bar) to
edit.
In PAD mode, they
become scale shift
switches.
16： Parameter
Pads
Press the parameter to
edit.
Press the function
button simultaneously
to select in PAD mode.
17：Track Pads
Select a TRACK and
trigger its sound.
Press the function
button simultaneously
to select without
sounding.
18：Power Switch
Press holding to turn on
and o󱐯 power.
19：D C12 V
Connect DC power
supply.
20：Output L/R
Stereo line level
audio output.
21：Input L/R
L Input can be connected
to an E.Guitar.R Input
can be connected to a
Dynamic Microphone.
22：MIDI In/Out
Input and Output for
MIDI signal.
23：USB Connector
Connect to PC, it can be
managed data and use
Audio Interface function.
24：Storage Card
Lo-12 XT internal data
storage card
25：Headphone Out
Stereo headphones
output.
