note
Although building codes have been considered in developing all drawings, verication of site-specic
conditions and compliance with federal, state and local building codes is the exclusive responsibility of
the customer and/or architect and engineer.
Water
e Customer’s Plumber is to provide and install a 3/4 inch city water line @60PSI (nominal) to the solenoid
valve on the chemical distribution system for the Wrap.
Electrical
e Customer’s Electrician is to provide and install single phase power from the Customer’s remote
push-button station through the tunnel equipment controller to the supplied air solenoid valve for retract
of both wraparound brushes upon selective signal (see Figure #5 in Dimensions Section).e Customer’s
Electrician is to provide materials and install single phase power from the Customer’s equipment program-
mer (equipment start-stop system) to the actuation controls for each electric motor on the air dryer.
e Customer’s Electrician is to provide materials and install 208VAC or 230VAC or 460VAC, 3-phase,
60Hz power to the electric motor on the hydraulic power pack or VFD panel from a properly sized three
pole circuit breaker and motor starter with three thermal overloads.
Compressed Air
e Customer’s Plumber is to provide and install a 3/8 inch compressed air line (1.5CFM @ 100PSI) from
the Air Compressor to the supplied Air Distribution Manifold for Retract functions.
e Customer’s Plumber is to provide and install a 3/8 inch compressed air line (1.5CFM @ 100PSI) from
the Air Compressor to the supplied Air-Driven Pump Station for Foamer Chemical Application functions.
