Owner's Manual
Wrap Around Washer - SF Wrap Series
SonnysDirect.com This document is confidential and proprietary to SONNY’S and cannot be used,
disclosed or duplicated without prior written consent. Content, prices and availability subject to change without notice
Rev. 1.0 3 Wrap Around-RevB
3. Equipment Measurements
Figure 1. Free Standing Wraps - Sheet 1
Centerline is measured 27 inches from the inside
passenger guide rail towards the pit wall.
There should be a five inch gap from the pit wall to the
centerline.
